| Supply System | 11 KV |
| Rated Service Voltage | 3 Phase, 3 Wire |
| Rated Insulation Voltage | RMS : 28 KV |
| PEAK : 75 KV | |
| Rated Current | Up To 1250 A |
| Rated Frequency | 50 Hz |
| Short Time Withstand Current | 26.3 KA For 3 seconds |
| Peak Withstand Current | 66 KA |
| Degree of Protection Overall | IP:5X |
